PREFACE
This flush mount, alternator tachometer is designed for use on the following:
Johnson® and Evinrude® Outboards
OMC Sea Drive® Models
NON-BRP products with 20 pole alternators
Installation
Disconnect battery cables to help prevent arcing or damage to equipment.
Select a tachometer mounting location that is in full view of the operator.
Drill a 3-3/8 in. (86mm) hole in the dashboard.
Mount the tachometer so water will not collect on the face, or drip on the case and wires. If the tachometer is covered by a transparent shield, the shield must be adequately ventilated to help prevent sunlight heat soak damage.
Set Pulse Selector Switch
[1]
Align the arrow on the PUL/REV (pulses-per-revolution) switch (A) with the appropriate number.
Engines with two yellow stator wires (yellow and yellow/gray) set switch to '6'
Engines with three yellow stator wires (yellow, yellow/gray and yellow/blue) set switch to '5'
NON-BRP engines with 20 pole charging system, set switch to '3'
1968 THRU 1972 Outboards
If you are replacing an older Battery CD Ignition tachometer, or if the engine has never had a tachometer, move the engine harness gray wire to the rectifier yellow/gray circuit on the terminal board.
1978 and Newer Outboard and OMC Sea Drive
Use a wiring kit to connect the tachometer to the plug-in connector on the remote control or accessory electrical cable.
Use Plug-In Connector Kit P/N 0174732 when installing tachometer only.
Use Plug-In/Fuse Block Kit P/N 0173611 when installing tachometer with other accessories.
All Models
Use No. 8 insulated ring terminals and No. 16 A.W.G. wire of the specified color.
[1]
HELPFUL HINT: install star washer, ring terminal, and nut - in that order. This will help prevent ring terminal from rotating and loosening the nut. Connect all wires before installing gauge in dashboard.
Omc Control Box Manual
[1]
Connect the following:
(B) To dashboard light switch, DARK BLUE WIRE.
(C) To alternator, GRAY WIRE.
(D) To ground connection, BLACK WIRE.
(E) To key switch accessory terminal, PURPLE WIRE.
Insert the gauge into dashboard. Install bracket, star washers, and mounting nuts.
Omc Control Box Manual Evinrude
Do not overtighten the mounting nuts as you could permanently damage the gauge.
Connect battery cables. Test the tachometer operation by running the engine.
Important: Multiple battery installations require a common battery ground cable. Refer to Outboard Installation Guidelines P/N 0508167.
Omc Remote Control Box Manual
[1]
To replace the light bulb, pry out light socket cover (F). Turn bulb socket counter-clockwise and pull out. Replace with a No. 194 bulb, P/N 0125432.
