VPS Scope is a free spectrum analyzer and scope analyzer and correlation meter VST, VST3, Audio Unit, AAX plugin developed by Vengeance Sound. Compatible OS(s): Windows 64b, macOS. VPS Scope is an analyser plugin with scope, spectral and stereo analysis: supports different VU metering modes. Synced & free running, zoomable realtime waveform. FREE Scope / Overview. A free analyser plug-in with scope, screctral and stereo field analyse capabilities! This plugin is free for all customers. This means you need to have at least 1 Vengeance DONGLE BASED product with a license key on your dongle to use it. This means all our products except VPS Avenger (which does not use a Dongle).
s(M)exoscope - VST oscilloscope |
s(M)exoscope is an oscilloscope VST plugin. You can use it to visually monitor audio wave forms.Why would you do this? Well, why not? There are countless times when being able to see what your audio waveform looks like could be useful. You'll know when the time is right. For all those other times, well, it's very pretty to look at! |
The Controls
Display controls
Retrigger modes
External mode, and Retrigger threshold
s(M)exoscope options
Analysis Tool
The Versions
standard
modular
The Controls |
Display controls |
Both of these knobs control the oscilloscope display. Time controls the number of pixels per sample. The lower the number, the finer the resolution of the waveform. The lowest value is 31.62 pixels to draw every sample, and the highest setting is 0.001... meaning that every pixel of length represents 1000 samples. The waveform itself will change colours to indicate if it is above or below 1 sample per pixel. At a Time of 1 or lower, a grey waveform display shows that more than one sample is compressed into each pixel. When Time is set higher than 1, a blue waveform indicates that the resolution uses more pixels to draw each sample. The figure below demonstrates the differences between extreme time settings. Amp controls the amplitude of the waveform in the display. Simplicity itself: if your waveform is too thin, crank it up! Cut off at the top and bottom of the display window? Turn that amp down. |
Retrigger modes |
S(M)exoscope has four modes (note that the modular version of the plugin has five modes. See below for more details) to determine how often it erases the display and starts drawing again (retriggers). Click the display mode button to cycle between the modes. Free mode is the default, and means that the display never erases and immediately starts writing again at the left as soon as the waveform reaches the right side of the display area. Internal mode retriggers the display at a frequency set by the Internal Trig Speed knob. Values are measured in Hz, and retrigger rates range from as infrequently as 0.441 Hz to as often as 139.4 times a second. This mode is useful if you only want to watch a certain part of a waveform. Rising This mode retriggers the display every time a waveform peak rises past a certain level. Drag the level slider (to the left of the display) to set the retrigger level above or below the zero crossing. The retrigger level is indicated by the white line. Falling Identical to Rising mode, except that the display retriggers only when the waveform falls past the retrigger level. |
External mode, and Retrigger threshold |
External is the fifth mode, available only in the modular version of s(M)exoscope. In this mode, the display retriggers whenever a trigger -- that is, a sample value of 1 -- is received by the plugin's trigger input. See below for more details on the modular version. In all modes, the Retrigger Threshold knob determines how soon the display can be retriggered after the last trigger. This threshold is measured in a number of samples. For example, if the Retrigger Threshold is set to 450, then the display will not retrigger unless at least 450 samples have passed through the display since the last retrigger. Useful if you absolutely need to see a certain number of samples in your waveform before it refreshes. Minimum: 1 sample, maximum: 10000 samples. |
s(M)exoscope options |
There are four option buttons you can use to customize the oscilliscope's behaviour even further. Sync Redraw, when activated, only updates waveform data when the plugin's internal graphic buffer is full (as opposed to in real-time). In other words, turn this on to slow down how often the display refreshes, and adjust the Time knob again to find the right speed. Freeze -- self-explanatory (but here you go anyways). Click this button to freeze the waveform in the display. DC-Kill -- click this button to automatically compensate for DC offset, if your waveform is too far off the zero crossing line. Channel -- click this button to toggle the displayed waveform between the right and left audio channels. |
Analysis Tool | |
Waveform analysis | |
The s(M)exoscope also contains a tool that can be used to analyze the waveform currently in the display. Based on where you place a marker, the tool analyzes the x and y dimensions of the waveform to calculate the following:
To use the analysis tool, just left-click anywhere on the s(M)exoscope display, and drag the pointer until you've reached the desired position. The analysis tool always measures from the beginning of the display. It's often useful to use the Freeze control to lock in the display first, then to measure what you see. In the example below, s(M)exoscope is measuring a simple sine wave sample, whose frequency we don't know. The display was frozen at a point where the waveform begins right at the left side of the display, and then measured to the beginning of the next cycle. The result in this case? A 440 Hz tone. Correct! To clear the analysis, right-click anywhere on the display area. |
The Versions | |
Standard or modular? | There are two versions of the oscilloscope: s(M)exoscope is the standard insert effect version, good to use in any VST host, and s(M)exoscopeModular, optimized especially for modular VST hosts like Plogue Bidule or AudioMulch. The module icons from Plogue Bidule (below, left column) best illustrate the differences between the two. |
The standard version, as mentioned before, is used as an insert effect. The plugin has stereo inputs, and audio from the track/channel on which the plugin is inserted passes through it unaltered. This version has only four retrigger modes: free, internal, rising, and falling. Basically, you should install only this version of the plugin, unless you are using a modular host. | |
The modular version of s(M)exoscope is identical in operation to the standard version, except for three points:
|
Scope Vst Free Download
MacOS
Windows 10 - 64bit
Windows 10 64bit – only
7 SP1, 8 and 8.1 not supported
Version 21.04.1.50040
MacOS
Schope Vst Free
Windows 32bit
How To Install Flux:: Center
OpenGL 2.0 required
Mac Pro 1.1 & Mac Pro 2.1 are NOT supported.
- Locate and double click the .dmg archive folder containing the Flux:: Center Installation file. (It will usually be in your Downloads folder.)
- To install Flux:: Center, simply drag the Center icon to the Applications folder, following the purple arrow.
- Launch the Flux:: Center application from the Applications folder.
- For instructions on how to install Flux:: applications and plug-ins using Flux:: Center, watch the video below.
How To Install Flux:: Center
OpenGL 2.0 required – If your computer has an ATi or NVidia graphics card, please assure the latest graphic drivers from the ATi or NVidia website are installed.
Schope Vst Free Download
- Locate and double-click the Flux:: Center Installation file. (It will usually be in your Downloads folder.)
- When the installer window opens, a dialog box will appear. Follow the instructions to install Flux:: Center.
- During the installation process you may be prompted to install additional software components, these are required by our software, and to avoid problems with using our software we recommend you to follow through with this installation.
- Launch the Flux:: Center application via the desktop shortcut or go to the start menu and type: center
- For instructions on how to install Flux:: applications and plug-ins using Flux:: Center, watch the video below.
WINDOWS USERS – IMPORTANT
PLEASE READ THIS!
Before using Center for the first time, ALL previously installed Flux:: / Ircam / Jünger software MUST BE UNINSTALLED from the Control Panel Add/Remove Programs.
License Activation
Schope Vst Free Downloads
The latest version of iLok License Manager is required for all products (Except Freeware).
Legacy Installer Downloads
Download Pro Tools 10 HD-X Installers
To use the AAX DSP version of our plug-ins in Pro Tools 10 HD-X on Mac OS X use these installers
Archives (Legacy Installers)
The archives contains legacy versions of our software that are no longer maintained and available without any support. For questions about the content of the archives, please contact support@flux.audio
